Ref. FV600/2S
Transient surge protection. 230/400V DC (50 - 60 Hz).
Transient surge protection 600 VDC. Voltage max. 720VDC. Type II. I nom. décharge 20 kA. I max discharge 40 kA. With auxiliar contacts. Visual status indicator.
Common applications: Indoor domestic / tertiary environment (Interior of home, offices, shops, etc.)
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Protection type (modular) Transient surge protector
No. of poles 2P
Modules (18 mm) 2
Network type Direct current (c / c)
Fixation 35mm DIN rail
Connection capacity Up to 35 mm²
Nominal voltage 600Vdc
Technical data and regulation
Technical data
Protection Degree (IP) IP20
Ambient operating temperature -40 ºC ; +85 ºC
Free of halogens Yes
Regulations
CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 50539-11:2013
According to REBT Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) The box does not correspond to the definition of Electrical and Electronical Equipment (EEE), but the included devices are affected individually.
According to European Directive 2012/19/UE (RAEE2) The box does not correspond to the definition of Electrical and Electronical Equipment (EEE), but the included devices are affected individually.
According to Regulations (RoHS) UNE-EN IEC 63000:2022
Logistics and packaging
Unit EAN code 8423220227699
EAN code container 8423220227699
EAN code packaging 18423220227696
Units packaging 1
Units carton 40
Pallet Units 999
Tariff code 85371098
