6762/1
CE marking
According to European Directive 2011/65/UE (RoHS)

Ref. 6762/1

Cable extension 2P+E, 16A 250V~. White colour. 2 m of cable.

Cable extension 2P+E, 16A 250V~. White colour. 2 m of cable.MAX. 3680W. Cable H05VV-F 3G1,5 mm².


Common applications: Indoor domestic / tertiary environment (Interior of home, offices, shops, etc.)

Add to zip Added to zip
Add to my downloads
Added to my downloads
More info
Download product sheet
Select the information you want to export:
Add to zip Added to zip
Add to my downloads
Added to my downloads
More info

Complementary products

MUR36U ERP60/2U 8013IL

Features

Type Extension
No. of bases 1
Basic characteristics 2P+E, 16A 250V~
Cable length 2 m.
Maximum power 3.680 W
Cable Yes
Cable Features H05VV-F 3G1,5mm²
sketch

Technical data and regulation

Technical data

Fire resistance (GWEPT) 750 ºC
Heat resistance (Ball pressure) 70/125 ºC

Regulations

CE marking Yes
According to Regulations UNE/EN UNE 20315-2-7:2008
According to REBT Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes

Sustainability

According to European Directive 2011/65/UE (RoHS) Yes
According to European Directive 2012/19/UE (RAEE2) Yes
According to Regulations (RoHS) UNE-EN IEC 63000:2022

Logistics and packaging

Unit EAN code 8423220063921
EAN code container 8423220063921
EAN code packaging 18423220063928
Units packaging 1
Units carton 40
Pallet Units 1400
Packaging Measures cm 59,5x20x37,5
Unit weight (g) 351
Container Weight (Kg) 0,38
Packaging Weight (Kg) 15,70
Tariff code 85366990

Documentation and downloads

Technical sheet Ref. 6762/1
UE Declaration of conformity Ref. 6762/1
Safety Information

Complementary products

MUR36U Socket 2P+E, 16A 250V~ + Double 2-way switch 10AX 250V~. Surface. ERP60/2U Double socket 2P+E, 16A 250V~. Monobloc. Flush. 8013IL Cable extension with 3 sockets 2P+E, 16A 250V~. With light switch. 1,5 m of cable.
