Ref. 933433
Industrial flush interlocked socket 2P+E, 32A 230V~. IP67
Flush-mounted industrial base with interlock system to prevent disconnection under load. Features 2 poles + earth and rated for 32A at 230V~. The IP67 rating offers full protection against water and dust. The interlock ensures current is only delivered when the plug is fully inserted, providing safe operation in demanding single-phase industrial environments.
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Common applications Industrial environments (factories, warehouses, etc.)
Type Base interblocante trascuadro
No. of poles 2P + T
Type of terminal connection Screw connection
Earth position 6h
Interlocking Yes
Frame for Indubox MR1300X
Nominal current 32A
Nominal voltage 230V
Color Blue
Technical data and regulation
Technical data
Protection Degree (IP) IP67
Protection Degree (IK) IK09
Impact shock resistance Strong
Fire resistance (GWEPT) 850 ºC
Heat resistance (Ball pressure) 125 ºC
Ambient operating temperature -5 ºC ; +40 ºC
Dimensional stability -25 ºC -> +80 ºC
Free of halogens Yes
Regulations
CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 60309-1:2023
UNE-EN 60309-2:2023
UNE-EN 60309-2:2023
According to REBT Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) Yes
According to European Directive 2012/19/UE (RAEE2) Yes
According to Regulations (RoHS) UNE-EN IEC 63000:2022
Logistics and packaging
Unit EAN code 8423220043404
EAN code container 8423220043404
EAN code packaging 18423220043401
Units packaging 0
Units carton 1
Pallet Units 99999
Packaging Measures cm 19,5x11x14
Unit weight (g) 0
Container Weight (Kg) 0
Packaging Weight (Kg) 0,718
Tariff code 85366990
