Ref. 931444A
Angled industrial flush socket 3P+E, 32A 400V~. IP67.
Angled industrial flush socket 3P+E, 32A 400V~. IP67.
Common applications: Industrial environments (factories, warehouses, etc.)
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Type Fitted socket outlet
No. of poles 3P + T
Type of terminal connection Screw connection
Earth position 6h
Frame for Indubox KIT-B
Nominal current 32A
Nominal voltage 400V
Color Red
Technical data and regulation
Technical data
Protection Degree (IP) IP67
Protection Degree (IK) IK09
Impact shock resistance Strong
Fire resistance (GWEPT) 850 ºC
Heat resistance (Ball pressure) 125 ºC
Ambient operating temperature -5 ºC ; +40 ºC
Dimensional stability -25 ºC -> +80 ºC
Free of halogens Yes
Regulations
CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 60309-1:2023
UNE-EN 60309-2:2023
UNE-EN 60309-2:2023
According to REBT Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) Yes
According to European Directive 2012/19/UE (RAEE2) Yes
According to Regulations (RoHS) UNE-EN IEC 63000:2022
Logistics and packaging
Unit EAN code 8423220043039
EAN code container 8423220043039
EAN code packaging 18423220043036
Units packaging 1
Units carton 10
Pallet Units 99999
Packaging Measures cm 29x23x19
Unit weight (g) 226
Container Weight (Kg) 0,23
Packaging Weight (Kg) 2,43
Tariff code 85366990
