Ref. 904014
Industrial triple adapter 2P+E, 16A 230V~.
Triple industrial adapter with 2P+T plug (6h), two industrial outlets (6h) and one domestic Schuko socket. Rated for 16A at 230V~ and up to 3680W. Features IP44 protection against dust and splashes. Ideal for powering both industrial and domestic devices at the same time in workshops, job sites, events or temporary setups.
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Common applications Industrial environments (factories, warehouses, etc.)
Type Adaptador industrial
No. of poles 2P + T
Type of terminal connection Screw connection
Earth position 6h
Nominal current 16A
Nominal voltage 230V
Color Blue
Technical data and regulation
Technical data
Protection Degree (IP) IP44
Protection Degree (IK) IK09
Impact shock resistance Strong
Fire resistance (GWEPT) 750 ºC
Heat resistance (Ball pressure) 125 ºC
Ambient operating temperature -5 ºC ; +40 ºC
Dimensional stability -25 ºC -> +80 ºC
Free of halogens Yes
Regulations
CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 60309-1:2023
UNE-EN 60309-2:2023
UNE-EN 60309-2:2023
According to REBT Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) Yes
According to European Directive 2012/19/UE (RAEE2) Yes
According to Regulations (RoHS) UNE-EN IEC 63000:2022
Logistics and packaging
Unit EAN code 8423220043497
EAN code container 8423220043497
EAN code packaging 18423220043494
Units packaging 1
Units carton 5
Pallet Units 99999
Packaging Measures cm 33x17x26
Unit weight (g) 481,8
Container Weight (Kg) 0,4818
Packaging Weight (Kg) 2,619
Tariff code 85366990
