Ref. 8684PF
Surface distribution board, 4 modules. Fume door.
Surface distribution board, 4 modules. Fume door.White box and frame. External dimensions 150 x 225 x 95 mm.
Common applications: Indoor domestic / tertiary environment (Interior of home, offices, shops, etc.)
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Enclosure type Distribution
Installation method Surface
Use Domestic / Tertiary
Location type Inside
No. Modules (18 mm) 4
Modules per row 4
Metallic DIN profile Yes
Dimensions outside (mm) (width x height x depth) 150x225x95
Dimensions (mm) See sketch
Case material Insulation
Frame and door material Insulation
Case color White
Cap color White
Door color Fume
Door opening Vertical
Battens included No
Ticket type Pre-punched
Fixation System (For surface) Inside
Sealable Not
Lid closure system Metal screw
Door closing system A Pressure
Reversible door Yes
Possibility of mounting strips Yes (not included)
Possibility of putting lock Key
Separate covers or doors on the boxes Yes
Possibility of mounting DIN rail Yes (included)
Additional dimensions (mm) See sketch
Technical data and regulation
Technical data
Protection Degree (IP) IP40
Protection Degree (IK) IK08
Insulation class Class II
Fire resistance (GWEPT) 650 ºC
Heat resistance (Ball pressure) 70 ºC
Installation temperature -5 ºC -> +60 ºC
Ambient operating temperature -5 ºC ; +60 ºC
Work stress <1000 Vac ; 1500 Vdc
Free of halogens Yes
Regulations
CE marking Yes
UK marking Yes
CMim marking Yes
According to Regulations UNE/EN UNE-EN 62208:2012
According to REBT Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) The Directive 2011/65/EU (RoHS II) is not applicable as it does not correspond to the definition of Electrical and Electronical Equipment (EEE) as per article 3.1
According to European Directive 2012/19/UE (RAEE2) Not applicable because it does not meet the definition of Electrical and Electronic Equipment (EEE) as described in Article 3.1(a) of Directive 2012/19/EU (WEEE II).
Logistics and packaging
Unit EAN code 8423220017535
EAN code container 8423220017535
EAN code packaging 18423220017532
Units packaging 1
Units carton 30
Pallet Units 360
Packaging Measurements cm 9,5x22,7x15
Packaging Measures cm 59,5x51x42,5
Unit weight (g) 510
Container Weight (Kg) 0,59
Packaging Weight (Kg) 18,96
Tariff code 85371098
Documentation and downloads
Distribution boards Arelos range (Solera) 2020
Montaje de las cajas de distribución de la serie Arelos (Solera)
