Ref. MUR63U
Socket 2P+E, 16A 250V ~ + 2-way switch 10AX 250V~. Surface.
Socket 2P+E, 16A 250V ~ + 2-way switch 10AX 250V~. Surface.White colour. Dimensions 138 x 72 x 42 mm. Inputs for 10x16, 10x20 and 16x16 mm mini-trunking. Screw connection.
Common applications: Indoor domestic / tertiary environment (Interior of home, offices, shops, etc.)
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Mechanism type switch + fixed base
Type of installation Surface
Nominal voltage 250V~ (50/60 Hz)
Connection type Screw connection
Mini trunking input Yes
Type of operation Rocker key
Dimensions 138 x 72 x 42
Monobloc (with frame included) Yes
Frame color White
Technical data and regulation
Technical data
Protection Degree (IP) IP20
Fire resistance (GWEPT) 750/850 ºC
Installation temperature -5 ºC -> +60 ºC
Free of halogens Yes
Regulations
CE marking Yes
According to Regulations UNE/EN UNE-EN 60669-1:2018
UNE 20315-1-1:2017
UNE-20315-1-2:2017
UNE 20315-1-1:2017
UNE-20315-1-2:2017
According to REBT Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) Yes
According to European Directive 2012/19/UE (RAEE2) Yes
According to Regulations (RoHS) UNE-EN IEC 63000:2022
Logistics and packaging
Unit EAN code 8423220095236
EAN code container 8423220095229
EAN code packaging 18423220095226
Units packaging 10
Units carton 120
Pallet Units 3240
Packaging Measurements cm 16x8x18
Packaging Measures cm 49,5x34x19
Unit weight (g) 65
Container Weight (Kg) 0,78
Packaging Weight (Kg) 10,01
Tariff code 85366990
Documentation and downloads
Surface switches Mural range (Solera)
Assembly surface switches Mural range (Solera)
