Ref. 3363FV
Sealed socket 2P+E (French) 16A 250V~ + sealed 2-way switch 10AX 250V~. Vertical. IP44. Surface.
Sealed socket 2P+E (French) 16A 250V~ + sealed 2-way switch 10AX 250V~. Vertical. IP44. Surface. Screw connection. Tube inputs up to Ø 20 mm. External dimensions 80 x 127 x 55 mm.
Common applications: Domestic / tertiary outdoor environment (garden, swimming pool, parking, public road, etc.)
Add to my downloads
Added to my downloads
Add to my downloads
Added to my downloads
Complementary products
Features
Mechanism type switch + fixed base
Rated current 16A
Nominal voltage 250V~ (50/60 Hz)
Connection type Screw connection
Tube inlet Up to Ø 20 mm
Flexible cable section Up to 2.5 mm²
Rigid cable section Up to 2.5 mm²
Type of operation Rocker key
Dimensions 127 x 80 x 55
Monobloc (with frame included) Yes
Frame color Grey
Technical data and regulation
Technical data
Protection Degree (IP) IP44
Insulation class Class II
Heat resistance (Ball pressure) 70/125 ºC
Installation temperature -5 ºC -> +60 ºC
Free of halogens Yes
Regulations
CE marking Yes
According to Regulations NF C61-314
According to Regulations UNE/EN UNE-EN 60669-1:2018
UNE 20315-1-1:2017
UNE-20315-1-2:2017
UNE 20315-1-1:2017
UNE-20315-1-2:2017
According to REBT Yes
NF certificate Yes
According to European Directive 2014/35 / EU. Low voltage directive Yes
Sustainability
According to European Directive 2011/65/UE (RoHS) Yes
According to European Directive 2012/19/UE (RAEE2) Yes
According to Regulations (RoHS) UNE-EN IEC 63000:2022
Logistics and packaging
Unit EAN code 8423220231993
EAN code container 8423220231986
EAN code packaging 18423220231983
Units packaging 10
Units carton 60
Pallet Units 1260
Packaging Measurements cm 28x14x19,5
Packaging Measures cm 45,5x30x41,5
Unit weight (g) 195
Container Weight (Kg) 2,06
Packaging Weight (Kg) 13,14
Tariff code 85366990
Documentation and downloads
Watertight switch IP54/44 (Solera)
Assembly watertight switches IP54/44 (Solera)
